🧬 Dynamic RNA velocity model-- (6) computational handling in implementation

Introduction

Although not explicitly stated in the scVelo paper, the dynamic model of RNA velocity relies heavily on the concept of neighbors. This is not merely a computational convenience– it’s a core principle in how scVelo interprets and visualizes RNA velocity data. In this blog, we unveil how scVelo leverages neighborhood information in its computations in section A).

In scVelo, certain functions are stochastic and depend on random seeds, while others are deterministic. Understanding the seed dependencies is crucial for reproducibility in RNA velocity analyses. Section B) provides a comprehensive overview of which scVelo functions rely on random seeds and which do not, essential to navigate the stochastic nature of scVelo functions for better reproducibility.

The object structure of scVelo illustrated in section C) focus on how gene-specific parameters and cell-and-gene-specific data are organized, the key to understanding how scVelo models RNA velocity at gene and cell levels.

Together, the insights presented here not only improve the accuracy of RNA velocity interpretation, but also empower users to identify and thoughtfully fine-tune key (hyper)parameters, enabling a more systematic and biologically meaningful analysis of single-cell datasets.

A) Steps in scVelo that Use Neighbors

1. scv.pp.moments(adata, …)

Uses: Nearest neighbors ( .obsp['distances'] and .obsp['connectivities'] ). It internally calls scv.pp.neighbors which in turn will call scanpy.pp.pca to compute PCA when adata.obsm['X_pca'] does not exist.

Purpose: To compute first- and second-order moments (mean and uncentered variance) of spliced and unspliced counts for each cell based on its local neighborhood.

The moments computation can be mathematically expressed as:

$$M_s^{(i)} = \sum_{j \in N(i)} w_{ij} \cdot s_j \tag{1}$$ $$M_u^{(i)} = \sum_{j \in N(i)} w_{ij} \cdot u_j \tag{2}$$

where $M_s^{(i)}$ and $M_u^{(i)}$ are the neighborhood-smoothed spliced and unspliced counts for cell $i$ , $N(i)$ represents the neighborhood of cell $i$ , and $w_{ij}$ are the connectivity weights.

These moments are directly used in:

scv.tl.velocity() – fits the model per gene
scv.tl.recover_dynamics() – if using dynamical model

Thus indirectly in all downstream velocity plotting/inference.

The use_raw parameter of scvelo.tl.recover_dynamics controls whether to use neighbors-smoothed moments or raw data as shown in: use_raw (bool or None (default: None)) -- if True, use .layers['spliced'], else use moments from .layers['Ms']

2. scv.tl.velocity_graph(adata)

Uses: .obsp['connectivities'] or recomputes internally if not present (deprecated).

Purpose: Computes a transition probability matrix (cosine similarity of velocity vectors) between neighboring cells.

The velocity graph computation involves:

$$V_{ij} = \frac{\vec{v}_i \cdot (\vec{x}_j - \vec{x}_i)}{|\vec{v}_i| \cdot |\vec{x}_j - \vec{x}_i|} \tag{3}$$

where $V_{ij}$ represents the transition probability from cell $i$ to cell $j$ , $\vec{v}_i$ is the velocity vector of cell $i$ , and $\vec{x}_j - \vec{x}_i$ is the displacement vector between cells.

Depends on: cell-cell proximity and velocity vectors – neighbor graph ensures computational efficiency and biological relevance.

3. scv.tl.latent_time(adata)

Uses: Neighbor-smoothed velocity graph to determine pseudotime-like ordering.

Purpose: Computes the global latent time based on inferred dynamics and the transition probabilities (again, neighbor-dependent).

The latent time computation can be expressed as:

$$t_{\text{latent}}^{(i)} = \sum_{j} V_{ij} \cdot t_j \tag{4}$$

where $t_{\text{latent}}^{(i)}$ is the latent time for cell $i$ , and the sum is over neighboring cells weighted by their transition probabilities $V_{ij}$ .

4. scv.pl.velocity_embedding_stream(…)

Indirectly uses: velocity_graph , which depends on the neighbor graph.

Purpose: Projects streamlines based on velocity vectors, assuming a local neighborhood flow.

The streamline projection follows the differential equation:

$$\frac{d\vec{x}}{dt} = \vec{v}(\vec{x}) \tag{5}$$

where $\vec{x}$ represents the position in embedding space and $\vec{v}(\vec{x})$ is the interpolated velocity field based on the neighbor-dependent velocity graph.

B) Random Seed Dependencies of scVelo Functions

Steps that depend on random seed

These functions contain stochastic elements and will produce different results with different random seeds.

Function	Description	Seed Dependency
`scv.pp.neighbors()`	Builds KNN graph, often used for velocity graph	✅ Yes - Approximate neighbors algorithms (e.g., `method='umap'` or `'hnsw'`) use randomization
`scv.tl.velocity_graph()`	Computes transition probabilities based on velocity vectors	✅ Yes - Uses neighbors graph and can have nondeterministic steps
`scv.tl.recover_dynamics()`	Fits the dynamical model to splicing kinetics (nonlinear optimization)	✅ Yes - Random initialization in curve fitting procedures
`scv.tl.latent_time()`	Estimates latent time based on gene likelihoods	✅ Yes - Depends on recovered dynamics which are stochastic
`scv.pl.velocity_embedding_stream()`	Stream plot of velocities on embedding	✅ Yes - Depends on UMAP randomness and interpolation grid seed
`scv.tl.velocity_pseudotime()`	Alternative to latent time, based on velocity graph	✅ Yes - Velocity graph contains randomness
`sc.tl.umap()` (from Scanpy)	Embedding used for velocity visualization	✅ Yes - UMAP uses random initialization

Reproducibility Tip: Set random seeds before running these functions to ensure reproducible results across different runs.

Steps that do not depend on random seed

These functions are deterministic and will produce identical results given the same input data.

Function	Description	Seed Dependency
`scv.pp.filter_and_normalize()`	Basic filtering and normalization	❌ No - Purely deterministic operations
`scv.pp.moments()`	Computes first and second moments for smoothing	❌ No - Deterministic given neighbors graph
`scv.tl.velocity()`	Computes RNA velocity using stochastic/dynamical model	❌ Mostly deterministic - Depends on moments and model parameters

Best Practices for Reproducibility

Setting Random Seeds

import numpy as np
import random

# Set global random seeds
np.random.seed(42)
random.seed(42)

# For specific functions, you can also set seeds locally
scv.settings.set_figure_params('scvelo', dpi_save=300, dpi=80, transparent=True, fontsize=14, color_map='viridis')

Workflow Recommendations

Set seeds early in your analysis pipeline
Document seed values used in your analysis
Test sensitivity by running with multiple different seeds
Save intermediate results after computationally expensive stochastic steps

C) scVelo object structure

Gene-specific parameters (same for all cells)

.var['fit_alpha'] - Transcription rate for each gene ( $\alpha_g$ )
.var['fit_beta'] - Splicing rate for each gene ( $\beta_g$ )
.var['fit_gamma'] - Degradation rate for each gene ( $\gamma_g$ )
.var['fit_t_'] - Switching time for each gene ( $t_{switch,g}$ )

Dimensions: $(n_{genes},)$ - one value per gene

Cell-and-gene-specific data

.layers['fit_t'] - Latent time varies by both cell AND gene ( $t_{c,g}$ )
.layers['velocity'] - Velocity varies by both cell AND gene ( $v_{c,g}$ )

Dimensions: $(n_{cells} \times n_{genes})$ - different value for each cell-gene combination

Mathematical representation

For a given gene $g$ and cell $c$ :

$$ \begin{align} \alpha_g &= \text{transcription rate (gene-specific)} \\ \beta_g &= \text{splicing rate (gene-specific)} \\ \gamma_g &= \text{degradation rate (gene-specific)} \\ t_{c,g} &= \text{latent time (cell- and gene-specific)} \\ v_{c,g} &= \text{velocity (cell- and gene-specific)} \end{align} $$

Why this makes sense biologically

Each gene has intrinsic kinetic properties - the rates $\alpha_g$, $\beta_g$, $\gamma_g$ describe how fast the gene transcribes, splices, and degrades
But different cells are at different stages of the process for each gene - the latent time $t_{c,g}$ varies
The rates are gene properties, the timing/stage varies by cell

This means:

If you want to compare kinetic rates between genes → look at .var
If you want to see where different cells are in the process for a specific gene → look at .layers['fit_t']

Data access patterns

# Same gene has same intrinsic kinetic rates across all cells
gene_alpha = adata.var['fit_alpha']['Ins1']  # α_Ins1 (same for all cells)
gene_beta = adata.var['fit_beta']['Ins1']    # β_Ins1 (same for all cells)
gene_gamma = adata.var['fit_gamma']['Ins1']  # γ_Ins1 (same for all cells)

# But latent time varies per cell for the same gene
ins1_latent_times = adata.layers['fit_t'][:, gene_idx]  # t_c,Ins1 (different per cell)
# Cell 1 might be at t=0.2, Cell 2 at t=0.8 for the same gene
